Drawing Agent

About

Drawing Agent converts precise industrial 2D drawings into fully editable 3D CAD models with millimetre accuracy. It does not produce approximate meshes that only resemble the original. The process works by generating CadQuery code, rendering the 3D model from various angles, and using an AI evaluator to compare each view against your drawing. The code is then rewritten until all dimensions align. The final output is a B-Rep solid, available in STEP, STL, or GLB formats, which opens directly in applications like SolidWorks, Fusion 360, or Inventor with every edge correctly sized. It also includes the Python source code for verification.
